The Soundcraft CPS2000 is a high-performance linear power supply designed specifically for large-format Soundcraft mixing consoles, such as the MH4, Series Five, and Series Four. It is built to handle the heavy current demands of professional sound reinforcement desks while maintaining low noise and high reliability.
Key Specifications & Features
- Voltage Output: Provides multiple DC rails including +/-17V at 16 Amps, +8V at 1.25 Amp, and +48V Phantom Power at 0.3 Amp.
- Cooling System: Features a heavy-duty design with substantial heat sinks and two internal fans to manage the significant heat generated during voltage regulation.
- Form Factor: Occupies 4U of rack space in a standard 19-inch rack unit.
- Redundancy: Two CPS2000 units can be diode-linked to provide automatic power backup; if one unit fails, the second takes over seamlessly to prevent audio interruption.
- Monitoring: The front panel includes operation LEDs for each regulating circuit and a digital voltmeter to monitor incoming mains voltage.
